Show Port Monitor - SMC Networks 8126PL2-F - annexe 1 Management Manual

Example
The following example configures the switch to mirror received packets from port 6
to 11:
Console(config)#interface ethernet 1/11
Console(config-if)#port monitor ethernet 1/6 rx
Console(config-if)#

show port monitor

This command displays mirror information.
Syntax
show port monitor [interface]
interface - ethernet unit/port (source port)
• unit - Stack unit. (Range: 1)
• port - Port number. (Range: 1-26/50)
Default Setting
Shows all sessions.
Command Mode
Privileged Exec
Command Usage
This command displays the currently configured source port, destination port,
and mirror mode (i.e., RX, TX).
Example
The following shows mirroring configured from port 6 to port 11:
Console(config)#interface ethernet 1/11
Console(config-if)#port monitor ethernet 1/6 rx
Console(config-if)#end
Console#show port monitor
Port Mirroring
-------------------------------------
Destination port(listen port):Eth1/11
Source port(monitored port)
Mode
Console#
:Eth1/6
:RX
Mirror Port Commands
4
4-179
