Displaying Port Members of Multicast Groups

You can display the multicast groups assigned to the MVR VLAN either through
IGMP snooping or static configuration.
Field Attributes
• Group IP – Multicast groups assigned to the MVR VLAN.
• Group Port List – Shows the interfaces with subscribers for multicast services
provided through the MVR VLAN.
Web – Click MVR, Group IP Information.
CLI – This example following shows information about the interfaces associated with
multicast groups assigned to the MVR VLAN.
Console#show mvr interface
MVR Group IP
---------------- -------- -------
225.0.0.1
225.0.0.2
225.0.0.3
225.0.0.4
225.0.0.5
225.0.0.6
225.0.0.7
225.0.0.8
225.0.0.9
225.0.0.10
Console#

Figure 3-132 MVR Group IP Information

Status Members
ACTIVE eth1/1(d), eth1/2(s)
INACTIVE None
INACTIVE None
INACTIVE None
INACTIVE None
INACTIVE None
INACTIVE None
INACTIVE None
INACTIVE None
INACTIVE None
