Configuring the Switch
Menu
Trunk Configuration
Tunnel Port Configuration
Tunnel Trunk Configuration Adds trunks to a QinQ tunnel
Private VLAN
Status
Link Status
Protocol VLAN
Configuration
Port Configuration
Priority
Default Port Priority
Default Trunk Priority
Traffic Classes
Traffic Classes Status
Queue Mode
Queue Scheduling
IP Precedence/DSCP Priority
Status
IP Precedence Priority
IP DSCP Priority
IP Port Priority Status
IP Port Priority
QoS
DiffServ
Class Map
Policy Map
Service Policy
IGMP Snooping
IGMP Configuration
IGMP Filter Configuration
3-8
Table 3-2 Main Menu (Continued)
Description
Specifies default trunk VID and VLAN attributes
Adds ports to a QinQ tunnel
Enables or disables the private VLAN
Configures the private VLAN
Configures protocol VLANs
Configures protocol VLAN port type, and associated protocol
VLANs
Sets the default priority for each port
Sets the default priority for each trunk
Maps IEEE 802.1p priority tags to output queues
Enables/disables traffic class priorities (not implemented)
Sets queue mode to strict priority or Weighted Round-Robin
Configures Weighted Round Robin queueing
Globally selects IP Precedence or DSCP Priority, or disables
both.
Sets IP Type of Service priority, mapping the precedence tag to
a class-of-service value
Sets IP Differentiated Services Code Point priority, mapping a
DSCP tag to a class-of-service value
Globally enables or disables IP Port Priority
Sets TCP/UDP port priority, defining the socket number and
associated class-of-service value
Quality of Service
Differentiated Services
Sets Class Maps
Sets Policy Maps
Defines service policy settings for ports
Enables multicast filtering; configures parameters for multicast
query
Enables IGMP filtering for the switch
