• Transmission Limit – The maximum transmission rate for BPDUs is specified by
setting the minimum interval between the transmission of consecutive protocol
messages. (Range: 1-10; Default: 3)
Configuration Settings for MSTP
• Max Instance Numbers – The maximum number of MSTP instances to which this
switch can be assigned.
• Configuration Digest – An MD5 signature key that contains the VLAN ID to MST
ID mapping table. In other words, this key is a mapping of all VLANs to the CIST.
• Region Revision
10
• Region Name
• Maximum Hop Count – The maximum number of hops allowed in the MST region
before a BPDU is discarded. (Range: 1-40; Default: 20)
10. The MST name and revision number are both required to uniquely identify an MST region.
10
– The revision for this MSTI. (Range: 0-65535; Default: 0)
– The name for this MSTI. (Maximum length: 32 characters)
Spanning Tree Algorithm Configuration
