INSTALLATION GUIDE

ta
TigerStack II 10/100/1000
SMC8926EM
24/48-Port Stackable Layer 3 Gigabit
SMC8950EM
Switch

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TIGERSTACK II SMC8926EM and is the answer not in the manual?

Questions and answers

Related Manuals for SMC Networks TIGERSTACK II SMC8926EM

Summary of Contents for SMC Networks TIGERSTACK II SMC8926EM

  • Page 1: Installation Guide

    INSTALLATION GUIDE TigerStack II 10/100/1000 SMC8926EM 24/48-Port Stackable Layer 3 Gigabit SMC8950EM Switch...
  • Page 2 TigerStack II 10/100/1000 Installation Guide From SMC's Tiger line of feature-rich workgroup LAN solutions 20 Mason Irvine, CA 92618 Phone: (949) 679-8000 August 2009 Pub. # 150200000054A E082009-MW-R01...
  • Page 3 Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable. However, no responsibility is assumed by SMC for its use, nor for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of SMC.

  • Page 4: Warranty And Product Registration

    Warranty and Product Registration To register SMC products and to review the detailed warranty statement, please refer to the Support Section of the SMC Website at http://www.smc.com.

  • Page 5: Compliances And Safety Warnings

    Compliances and Safety Warnings FCC - Class A This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 6: Ce Mark Declaration Of Conformance For Emi And Safety (Eec)

    CE Mark Declaration of Conformance for EMI and Safety (EEC) This information technology equipment complies with the requirements of the Council Directive 89/336/EEC on the Approximation of the laws of the Member States relating to Electromagnetic Compatibility and 73/23/EEC for electrical equipment used within certain voltage limits and the Amendment Directive 93/68/EEC.

  • Page 7: Safety Compliance

    ないで下さい。 Power Cord Safety Please read the following safety information carefully before installing the switch: WARNING: Installation and removal of the unit must be carried out by qualified personnel only. • The unit must be connected to an earthed (grounded) outlet to comply with international safety standards.

  • Page 8: Veuillez Lire À Fond L'information De La Sécurité Suivante Avant D'installer Le Switch

    HO3VVF3GO.75 (minimum). IEC-320 receptacle. Veuillez lire à fond l'information de la sécurité suivante avant d'installer le Switch: AVERTISSEMENT: L’installation et la dépose de ce groupe doivent être confiés à un personnel qualifié. • Ne branchez pas votre appareil sur une prise secteur (alimentation électrique) lorsqu'il n'y a pas de connexion de mise à...

  • Page 9: Bitte Unbedingt Vor Dem Einbauen Des Switches Die Folgenden Sicherheitsanweisungen Durchlesen

    France et Pérou uniquement: Ce groupe ne peut pas être alimenté par un dispositif à impédance à la terre. Si vos alimentations sont du type impédance à la terre, ce groupe doit être alimenté par une tension de 230 V (2 P+T) par le biais d’un transformateur d’isolement à rapport 1:1, avec un point secondaire de connexion portant l’appellation Neutre et avec raccordement direct à...

  • Page 10: Warnings And Cautionary Messages

    Warning: This switch uses lasers to transmit signals over fiber optic cable. The lasers are compliant with the requirements of a Class 1 Laser Product and are inherently eye safe in normal operation. However, you should never look directly at a transmit port when it is powered on.
  • Page 11 Documentation All printed documentation for this product uses biodegradable paper that originates from sustained and managed forests. The inks used in the printing process are non-toxic.

  • Page 12: Revision History

    The following publication gives specific information on how to operate and use the management functions of the switch: The Management Guide Also, as part of the switch’s software, there is an online web-based help that describes all management related features.s Revision History This section summarizes the changes in each revision of this guide.

  • Page 13: Table Of Contents

    Application Examples Collapsed Backbone Network Aggregation Plan Remote Connections with Fiber Cable Making VLAN Connections Using Layer 3 Routing Application Notes Chapter 3: Installing the Switch Selecting a Site Ethernet Cabling Equipment Checklist Package Contents Optional Rack-Mounting Equipment Mounting Rack Mounting...
  • Page 14 Contents Desktop or Shelf Mounting Installing an Optional Module into the Switch Installing an Optional SFP Transceiver Connecting Switches in a Stack Stacking Topologies Connecting to a Power Source Connecting to the Console Port Wiring Map for Serial Cable Chapter 4: Making Network Connections...
  • Page 15 Appendix C: Specifications Physical Characteristics Switch Features Management Features Standards Compliances Extender Modules 10GBASE Extender Module (XFP) Glossary Index Contents...
  • Page 16 Tables Table 1-1 Port Status LEDs Table 1-2 System Status LEDs Table 1-3 Supported XFP Transceivers Table 1-4 Module LEDs Table 3-1 Serial Cable Wiring Table 4-1 Maximum 10GBASE-SR 10 Gigabit Ethernet Cable Length Table 4-2 Maximum 10GBASE-LR 10 Gigabit Ethernet Cable Length Table 4-3 Maximum 10GBASE-ER 10 Gigabit Ethernet Cable Length Table 4-4...
  • Page 17 IP Routing for Unicast Traffic Figure 3-1 RJ-45 Connections Figure 3-2 Attaching the Brackets Figure 3-3 Installing the Switch in a Rack Figure 3-4 Attaching the Adhesive Feet Figure 3-5 Installing an Optional Module Figure 3-6 Inserting an SFP Transceiver into a Slot...
  • Page 18 Figures...

  • Page 19: Chapter 1: Introduction

    Chapter 1: Introduction Overview The SMC8926EM and SMC8950EM are intelligent multilayer switches (Layer 2, 3) with 24/48 10/100/1000BASE-T ports, four of which are combination ports shared with four SFP transceiver slots (see Figure 1-1, Ports 21-24/45-48). The rear panel provides two slots for single-port 10 Gigabit Ethernet hot-swappable expansion modules, and two stacking ports.

  • Page 20: Switch Architecture

    These switches include built-in stacking ports that enable up to eight units to be connected together through a 48 Gbps stack backplane. The switch stack can be managed from a master unit using a single IP address.

  • Page 21: Figure

    Chapter 1: Introduction Overview The SMC8926EM and SMC8950EM are intelligent multilayer switches (Layer 2, 3) with 24/48 10/100/1000BASE-T ports, four of which are combination ports shared with four SFP transceiver slots (see Figure 1-1, Ports 21-24/45-48). The rear panel provides two slots for single-port 10 Gigabit Ethernet hot-swappable expansion modules, and two stacking ports.

  • Page 22: Table 1-1 Port Status Leds

    Introduction Condition Link/ On/Flashing Amber Port has a valid link at 10 or 100 Mbps. Flashing indicates activity. Activity/ On/Flashing Green Port has a valid link at 1000 Mbps. Flashing indicates activity. Speed System Status LEDs Stack Link Condition Power Green Amber Diag...

  • Page 23: Description Of Hardware

    Power Supply Sockets There are two power sockets on the rear panel of each switch. The standard power socket is for the AC power cord. The socket labeled “RPS” is for the optional Redundant Power Supply (RPS).

  • Page 24: Optional Media Extender Modules

    Introduction Optional Media Extender Modules 10GBASE XFP Module Figure 1-6 Single-Port 10GBASE Module (XFP) The module’s XFP slot supports standard 10 Gigabit Ethernet (10G) XFP transceivers. The 10GBASE transceivers operate at 10 Gbps full duplex with support for flow control. Extender Module LEDs The optional 10GBASE slide-in module includes its own integrated LED indicators on the module’s front panel.

  • Page 25: Expandability

    Management • “At-a-glance” LEDs for easy troubleshooting • Network management agent: - Manages switch (or entire stack) in-band or out-of-band - Supports console, Telnet, SSH, SNMP v1/v2c/v3, RMON (4 groups) and web-based interface • Slave units provide backup stack management.
  • Page 26 Introduction...

  • Page 27: Figure

    When networks are based on repeater (hub) technology, the distance between end stations is limited by a maximum hop count. However, a switch turns the hop count back to zero. So subdividing the network into smaller and more manageable segments, and linking them to the larger network by means of a switch, removes this limitation.

  • Page 28: Application Examples

    24/48 workstations or servers. You can easily build on this basic configuration, adding direct full-duplex connections to workstations or servers. When the time comes for further expansion, just connect to another hub or switch using one of the Gigabit Ethernet ports built into the front panel, a Gigabit Ethernet port on a plug-in SFP transceiver, or a 10G transceiver on an optional module.

  • Page 29: Network Aggregation Plan

    Network Aggregation Plan With 24 or 48 parallel bridging ports (i.e., 24 or 48 distinct collision domains), a Gigabit switch stack can collapse a complex network down into a single efficient bridged node, increasing overall bandwidth and throughput. In the figure below, the 10/100/1000BASE-T ports in a stack of 48-port Gigabit Ethernet switches are providing 1000 Mbps connectivity through stackable switches.

  • Page 30: Remote Connections With Fiber Cable

    1000BASE-SX (MMF) link can connect to a site up to 550 meters away, a 1000BASE-LX (SMF) link up to 5 km, and a 1000BASE-LH link up to 70 km. This allows a switch stack to serve as a collapsed backbone, providing direct connectivity for a widespread LAN.

  • Page 31: Making Vlan Connections

    R&D VLAN 1 Tagged Ports Finance VLAN 2 Testing VLAN 3 VLAN 4 Note: When connecting to a switch that does not support IEEE 802.1Q VLAN tags, use untagged ports. Untagged Ports VLAN unaware switch Marketing Finance VLAN 3 Figure 2-4 Making VLAN Connections...

  • Page 32: Using Layer 3 Routing

    Network Planning Using Layer 3 Routing VLANs can significantly enhance network performance and security. However, if you use conventional routers to interconnect VLANs, you can lose most of your performance advantage. These Gigabit Ethernet Switches are routing switches that provide wire-speed routing, which allows you to eliminate your conventional IP routers, except for a router to handle non-IP protocols and a gateway router linked to the WAN.

  • Page 33: Application Notes

    Application Notes Full-duplex operation only applies to point-to-point access (such as when a switch is attached to a workstation, server or another switch). When the switch is connected to a hub, both devices must operate in half-duplex mode. For network applications that require routing between dissimilar network types, you can attach these switches directly to a multi-protocol router.
  • Page 34 Network Planning...

  • Page 35: Chapter 3: Installing The Switch

    100BASE-TX, and Category 5, 5e or 6 for 1000BASE-T. • Protection from radio frequency interference emissions • Electrical surge suppression • Separation of electrical wires (switch related or other) and electromagnetic fields from data based network wiring • Safe connections with no damaged cables, connectors or shields...

  • Page 36: Equipment Checklist

    Installing the Switch Equipment Checklist After unpacking the switch, check the contents to be sure you have received all the components. Then, before beginning the installation, be sure you have all other necessary installation equipment. Package Contents • 24- or 48-port Gigabit Ethernet Switch (SMC8926EM or SMC8950EM) •...

  • Page 37: Mounting

    Mounting A switch unit can be mounted in a standard 19-inch equipment rack or on a desktop or shelf. Mounting instructions for each type of site follow. Rack Mounting Before rack mounting the switch, pay particular attention to the following factors: •...

  • Page 38: Desktop Or Shelf Mounting

    Mount the device in the rack, using four rack-mounting screws (not provided). Figure 3-3 Installing the Switch in a Rack If installing a single switch only, turn to "Connecting to a Power Source" at the end of this chapter. If installing multiple switches, mount them in the rack, one below the other, in any order.

  • Page 39: Installing An Optional Module Into The Switch

    If installing a single switch only, go to "Connecting to a Power Source" at the end of this chapter. If installing multiple switches, attach four adhesive feet to each one. Place each device squarely on top of the one below, in any order.

  • Page 40: Installing An Optional Sfp Transceiver

    Slide the SFP transceiver into the slot until it clicks into place. Note: SFP transceivers are hot-swappable. The switch does not need to be powered off before installing or removing a transceiver. However, always first disconnect the network cable before removing a transceiver.

  • Page 41: Connecting Switches In A Stack

    Figure 3-7 shows how the stack cables are connected between switches in a stack. Each stacking connection is a 48 Gbps full-duplex high-speed serial link using proprietary stacking cables. The switch supports a line- and ring-topology stacking configuration, or can be used stand alone. To ensure minimal disruption in case a unit or stacking cable fails, we recommend always use a ring-topology.

  • Page 42: Stacking Topologies

    Select the Master unit in the stack by pressing the Master button in on only one of the switches. Only one switch in the stack can operate as the Master, all other units operate in slave mode. If more than one switch in the stack is selected as Master, or if no switches are selected, the system will select the unit with the lowest MAC address as the Master.

  • Page 43: Connecting To The Console Port

    Connecting to the Console Port The RJ-45 serial port on the switch’s front panel is used to connect to the switch for out-of-band console configuration. The on-board configuration program can be accessed from a terminal or a PC running a terminal emulation program. The pin assignments used to connect to the serial port are provided in the following table.
  • Page 44 Installing the Switch 3-10...

  • Page 45: Chapter 4: Making Network Connections

    Chapter 4: Making Network Connections Connecting Network Devices This switch is designed to interconnect multiple segments (or collision domains). It can be connected to network cards in PCs and servers, as well as to hubs, switches or routers. It may also be connected to devices using optional XFP or SFP transceivers.

  • Page 46: Connecting To Pcs, Servers, Hubs And Switches

    Figure 4-1 Making Twisted-Pair Connections If the device is a PC card and the switch is in the wiring closet, attach the other end of the cable segment to a modular wall outlet that is connected to the wiring closet.

  • Page 47: Fiber Optic Sfp Devices

    Network Switch Figure 4-2 Network Wiring Connections Fiber Optic SFP Devices An optional Gigabit SFP transceiver (1000BASE-SX, 1000BASE-LX or 1000BASE-LH) can be used for a backbone connection between switches, or for connecting to a high-speed server. Each single-mode fiber port requires 9/125 micron single-mode fiber optic cable with an LC connector at both ends.

  • Page 48: 10 Gbps Fiber Optic Connections

    Making Network Connections Connect one end of the cable to the LC port on the switch and the other end to the LC port on the other device. Since LC connectors are keyed, the cable can be attached in only one orientation.

  • Page 49: Figure 4-4 Connecting To An Xfp Transceiver

    Connect one end of the cable to the LC port on the switch and the other end to the LC port on the other device. Since LC connectors are keyed, the cable can be attached in only one orientation.

  • Page 50: Connectivity Rules

    However, note that because switches break up the path for connected devices into separate collision domains, you should not include the switch or connected cabling in your calculations for cascade length involving other devices.

  • Page 51: 1000 Mbps Gigabit Ethernet Collision Domain

    1000 Mbps Gigabit Ethernet Collision Domain Table 4-4 Maximum 1000BASE-T Gigabit Ethernet Cable Length Cable Type Category 5, 5e, 6 100-ohm UTP or STP Table 4-5 Maximum 1000BASE-SX Gigabit Ethernet Cable Length Fiber Size 62.5/125 micron multimode fiber 50/125 micron multimode fiber Table 4-6 Maximum 1000BASE-LX Gigabit Ethernet Cable Length Fiber Size...

  • Page 52: Cable Labeling And Connection Records

    For each piece of equipment, identify the devices to which it is connected. • Note the length of each cable and the maximum cable length supported by the switch ports. • For ease of understanding, use a location-based key when assigning prefixes to your cable labeling.

  • Page 53: Appendix A: Troubleshooting

    • Power cycle the switch to try and clear the condition. • Verify that the switch and attached device are powered on. • Be sure the cable is plugged into both the switch and corresponding device. • Verify that the proper cable type is used and its length does not exceed specified limits.

  • Page 54: Power And Cooling Problems

    IP address. Also, be sure the port through which you are connecting to the switch has not been disabled. If it has not been disabled, then check the network cabling that runs between your remote location and the switch.

  • Page 55: Stack Troubleshooting

    Switches in the stack may be configured using a ring- or line-topology. To ensure minimal disruption in case a unit or stacking cable fails, always use a ring-topology. When using ring-topology configuration and a switch fails, or a stacking cable is disconnected, the stack continues normal operation using line-topology stacking through the remaining stack connections.
  • Page 56 Troubleshooting...

  • Page 57: Appendix B: Cables

    Category 5 cable for 100 Mbps connections. Also be sure that the length of any twisted-pair connection does not exceed 100 meters (328 feet). The RJ-45 ports on the switch base unit support automatic MDI/MDI-X operation, so you can use straight-through cables for all network connections to PCs or servers, or to other switches or hubs.

  • Page 58: Straight-Through Wiring

    Cables Table B-1 10/100BASE-TX MDI and MDI-X Port Pinouts Transmit Data plus (TD+) Transmit Data minus (TD-) Receive Data plus (RD+) Receive Data minus (RD-) Not used 4,5,7,8 Note: The “+” and “-” signs represent the polarity of the wires that make up each wire pair.

  • Page 59: 1000Base-T Pin Assignments

    You must connect all four wire pairs as shown in the following diagram to support Gigabit Ethernet connections. EIA/TIA 568B RJ-45 Wiring Standard End A 1000BASE-T Pin Assignments All 1000BASE-T ports support automatic MDI/MDI-X operation, so you can use straight-through cables for all network connections to PCs or servers, or to other switches or hubs.

  • Page 60: Cable Testing For Existing Category 5 Cable

    Cables Cable Testing for Existing Category 5 Cable Installed Category 5 cabling must pass tests for Attenuation, Near-End Crosstalk (NEXT), and Far-End Crosstalk (FEXT). This cable testing information is specified in the ANSI/TIA/EIA-TSB-67 standard. Additionally, cables must also pass test parameters for Return Loss and Equal-Level Far-End Crosstalk (ELFEXT).
  • Page 61 ITU-T Description Standard G.653 Dispersion-Shifted Fiber Single-mode, 9/125-micron core G.654 1550-nm Loss-Minimized FiberSingle-mode, 9/125-micron core G.655 Non-Zero Dispersion-Shifted FiberSingle-mode, 9/125-micron core Table B-3 Fiber Standards Application Longer spans and extended reach. Optimized for operation in the region from 1500 to 1600-nm. Extended long-haul applications.
  • Page 62 Cables...

  • Page 63: Appendix C: Specifications

    Appendix C: Specifications Physical Characteristics Ports SMC8926EM:20 10/100/1000BASE-T, with auto-negotiation 4 10/100/1000BASE-T shared with 4 SFP transceiver slots 2 10GBASE extender module slots for XFP transceivers Two slots for stacking transceivers SMC8950EM:44 10/100/1000BASE-T, with auto-negotiation 4 10/100/1000BASE-T shared with 4 SFP transceiver slots 2 10GBASE extender module slots for XFP transceivers Two slots for stacking transceivers Network Interface...
  • Page 64 Specifications Weight SMC8926EM: 3.72 kg (8.20 lbs) SMC8950EM: 4.34 kg (9.57 lbs) Size 44.0 x 33.1 x 4.4 cm (17.3 x 12.2 x 1.7 in.) Temperature Operating: 0 to 50 °C (32 to 122 °F) Storage: -40 to 70 °C (-40 to 158 °F) Humidity Operating: 5% to 95% (non-condensing) AC Input...

  • Page 65: Switch Features

    Switch Features Forwarding Mode Store-and-forward Throughput Wire speed Flow Control Full Duplex: IEEE 802.3x Half Duplex: Back pressure Management Features In-Band Management Web, Telnet, SSH, or SNMP manager Out-of-Band Management RS-232 RJ-45 console port Software Loading TFTP in-band, or XModem out-of-band Standards IEEE 802.3-2005...

  • Page 66: Compliances

    Specifications Compliances CE Mark Emissions FCC Class A Industry Canada Class A EN55022 (CISPR 22) Class A EN 61000-3-2/3 Immunity EN 61000-4-2/3/4/5/6/8/11 Safety UL 60950-1 & CSA 60950-1 IEC 60950-1 & EN 60950-1 Extender Modules 10GBASE Extender Module (XFP) Ports 1 slot for 10GBASE XFP transceiver Communication Speed 10 Gbps...

  • Page 67: Glossary

    Glossary 10BASE-T IEEE 802.3 specification for 10 Mbps Ethernet over two pairs of Category 3, 4, or 5 UTP cable. 100BASE-TX IEEE 802.3u specification for 100 Mbps Fast Ethernet over two pairs of Category 5 or better UTP cable. 1000BASE-LH Long-haul Gigabit Ethernet over two strands of 9/125 micron core fiber cable.
  • Page 68 Glossary Auto-Negotiation Signalling method allowing each node to select its optimum operational mode (e.g., speed and duplex mode) based on the capabilities of the node to which it is connected. Bandwidth The difference between the highest and lowest frequencies available for network signals.
  • Page 69 Glossary IEEE Institute of Electrical and Electronic Engineers. IEEE 802.3 Defines carrier sense multiple access with collision detection (CSMA/CD) access method and physical layer specifications. IEEE 802.3ab Defines CSMA/CD access method and physical layer specifications for 1000BASE-T Gigabit Ethernet. (Now incorporated in IEEE 802.3-2005.) IEEE 802.3ae Defines the physical layer specifications for 10 Gigabit Ethernet.
  • Page 70 Glossary units of MHz per km, which indicates the amount of bandwidth supported by the fiber for a one km distance. Network Diameter Wire distance between two end stations in the same collision domain. Redundant Power Supply (RPS) A backup power supply unit that automatically takes over in case the primary power supply should fail.

  • Page 71: Index

    4-3 full-duplex connectivity 2-1 IEEE 802.3 Ethernet 1-7 IEEE 802.3ae 10 Gigabit Ethernet 1-7 IEEE 802.3u Fast Ethernet 1-7 IEEE 802.3z Gigabit Ethernet 1-7 indicators, LED 1-3 installation connecting devices to the switch 4-2 desktop or shelf mounting 3-4 Index-1...
  • Page 72 3-1 management agent 1-2 features 1-7, C-3, C-4 out-of-band 1-2 SNMP 1-2 web-based 1-2 mounting the switch on a desktop or shelf 3-4 multimode fiber optic cables 4-3 network connections 4-1 examples 2-2 optional modules, installation 3-5 optional redundant power unit 1-5...
  • Page 73 VLANs routing 2-6 tagging 2-5 web-based management 1-2 Index Index-3...
  • Page 74 Index Index-4...
  • Page 76 SMC8926EM SMC8950EM 150200062800A R02 150200000054A R01 20 Mason • Irvine, CA 92618 • Phn: 949-679-8000 • www.smc.com...
