Frame Size Commands

Command

jumbo frame

jumbo frame
This command enables support for jumbo frames. Use the no form to disable it.
Syntax
[no] jumbo frame
Default Setting
Disabled
Command Mode
Global Configuration
Command Usage
• This switch provides more efficient throughput for large sequential data
transfers by supporting jumbo frames up to 10 KB for the Gigabit Ethernet
ports. Compared to standard Ethernet frames that run only up to 1.5 KB, using
jumbo frames significantly reduces the per-packet overhead required to
process protocol encapsulation fields.
• To use jumbo frames, both the source and destination end nodes (such as a
computer or server) must support this feature. Also, when the connection is
operating at full duplex, all switches in the network between the two end nodes
must be able to accept the extended frame size. And for half-duplex
connections, all devices in the collision domain would need to support jumbo
frames.
• Enabling jumbo frames will limit the maximum threshold for broadcast storm
control to 64 packets per second. (See the switchport broadcast command
on page 4-161.)
• The current setting for jumbo frames can be displayed with the show system
command (page 4-21).
Example
Console(config)#jumbo frame
Console(config)#

Table 4-9 Frame Size Commands

Function
Enables support for jumbo frames
System Management Commands
4
Mode Page
GC 4-23
4-23
