Web – Specify the action (i.e., Permit or Deny). Specify the source and/or
destination addresses. Select the address type (Any, Host, or MAC). If you select
"Host," enter a specific address (e.g., 11-22-33-44-55-66). If you select "MAC," enter
a base address and a hexadecimal bitmask for an address range. Set any other
required criteria, such as VID, Ethernet type, or packet format. Then click Add.
CLI – This example configures one permit rule for all source mac addresses to
communicate with all destination mac addresses on VLAN 12, and another permit
rule for source mac address to communicate with all destination mac addresses.
Console(config-mac-acl)#permit any any vid 12 4095
Console(config-mac-acl)#permit host 00-10-b5-e9-52-79 any
Console(config-mac-acl)#

Figure 3-59 Configuring MAC ACLs

Access Control Lists
4-150
3
3-97
