Configuring the Switch
CLI – This example shows the connection status for Port 5.
Console#show interfaces status ethernet 1/5
Information of Eth 1/5
Basic Information:
Port Type:
Mac Address:
Configuration:
Name:
Port Admin:
Speed-duplex:
Capabilities:
Broadcast Storm:
Broadcast Storm Limit:
Multicast Storm:
Multicast Storm Limit:
Unknown Unicast Storm:
Unknown Unicast Storm Limit:
Flow Control:
LACP:
Port Security:
Max MAC Count:
Port Security Action:
Media Type:
Current Status:
Link Status:
Port Operation Status:
Operation Speed-duplex:
Flow Control Type:
Console#

Configuring Interface Connections

You can use the Port Configuration or Trunk Configuration page to enable/disable an
interface, set auto-negotiation and the interface capabilities to advertise, or manually
fix the speed, duplex mode, and flow control.
Command Usage
• Auto-negotiation must be disabled before you can configure or force the interface
to use the Speed/Duplex Mode or Flow Control options.
• When using auto-negotiation, the optimal settings will be negotiated between the
link partners based on their advertised capabilities. To set the speed, duplex mode,
or flow control under auto-negotiation, the required operation modes must be
specified in the capabilities list for an interface.
• The 1000BASE-T standard does not support forced mode. Auto-negotiation
should always be used to establish a connection over any 1000BASE-T port or
trunk. If not used, the success of the link process cannot be guaranteed when
connecting to other types of switches.
Command Attributes
• Name – Allows you to label an interface. (Range: 1-64 characters)
• Admin – Allows you to manually disable an interface. You can disable an interface
due to abnormal behavior (e.g., excessive collisions), and then reenable it after the
3-114
1000T
00-13-F7-12-31-24
Up
Auto
10half, 10full, 100half, 100full,
1000full
Enabled
500 packets/second
Disabled
262143 packets/second
Disabled
262143 packets/second
Disabled
Disabled
Disabled
0
None
None
Up
Up
100full
None
4-163
