Web – Click IGMP Snooping, IGMP Filter Configuration. Create a profile number by
entering the number in text box and clicking Add. Enable the IGMP filter status, then
click Apply.
CLI – This example enables IGMP filtering and creates a profile number, then
displays the current status and the existing profile numbers.
Console(config)#ip igmp filter
Console(config)#ip igmp profile 19
Console(config-igmp-profile)#end
Console#show ip igmp filter
IGMP filter enable
Console#show ip igmp profile
IGMP Profile 19
IGMP Profile 50
IGMP Profile 60
Console#

Configuring IGMP Filter Profiles

When you have created an IGMP profile number, you can then configure the
multicast groups to filter and set the access mode.
Command Usage
• Each profile has only one access mode; either permit or deny.
• When the access mode is set to permit, IGMP join reports are processed when a
multicast group falls within the controlled range. When the access mode is set to
deny, IGMP join reports are only processed when a multicast group is not in the
controlled range.
Command Attributes
• Profile ID – Selects an existing profile number to configure. After selecting an ID
number, click the Query button to display the current configuration.

Figure 3-127 Enabling IGMP Filtering and Throttling

3
Multicast Filtering
4-277
4-278
4-281
4-282
3-219
