3
Configuring the Switch
• Enable Authentication Traps
trap managers whenever an invalid community string is submitted during the
SNMP access authentication process. (Default: Enabled)
• Enable Link-up and Link-down Traps
whenever a port link is established or broken. (Default: Enabled)
Web – Click SNMP, Configuration. Enter the IP address and community string for
each management station that will receive trap messages, specify the UDP port,
trap version, trap security level (for v3 clients), trap inform settings (for v2c/v3
clients), and then click Add. Select the trap types required using the check boxes for
Authentication and Link-up/down traps, and then click Apply.
CLI – This example adds a trap manager and enables both authentication and
link-up, link-down traps.
Console(config)#snmp-server host 192.168.1.19 private version 2c
Console(config)#snmp-server enable traps
3. These are legacy notifications and therefore when used for SNMP Version 3 hosts, they must be
enabled in conjunction with the corresponding entries in the Notification View (3-52).
3-42
3
– Issues a notification message to specified IP
3

Figure 3-26 Configuring IP Trap Managers

– Issues a notification message
4-65
4-67
