780B Video Generator/Analyzer – User Guide
Table 4-3: Test Patterns
Pattern Name
EMI/Grill
Applications:
EMI – Show grid of "H"
characters to check for EMI
effects on image. Each "H"
character should be clear and
distinct.
Grill – for verifying monitor
resolution.
Color Bars – To test a display's
ability to produce fully
saturated primary and
secondary color.
December 1, 2014
Variant
Overscan
EMI
EMI - Grill
EMI - ColorBars
Options
N/A
H Type
Grill On/Off
Scroll – Scrolls the "H" characters vertically.
Grill On/Off
Grill Mode
Scroll – color bars scroll horizontally.
Range of Values
Revision A7
Page 33
