780B Video Generator/Analyzer – User Guide
Table 11-1: List of Commands (alphabetical) – For Testing HDMI Sink Devices
Command Description
HSPG Sets enable gate of
the horizontal sync
pulse.
IMGL Loads an image
(pattern).
IMGU
Activates an image
that has been loaded
and queries for the
currently active image.
NBPC Sets or queries the
number of bits per
component. Applies
only to HDMI
PRAT? Queries the pixel rate
of the outgoing HDMI
format.
RGBW
Sets RGB values on
with Raster and
Window test patterns
SCAN
Defines whether the
active timing is
progressive or
interlaced or queries
the state of the active
timing.
SIRE Sets IRE levels for
certain images:
Window1/2, Raster,
Flat_Wht/Grn/
Red/Blu/Cyn/Mag/Blk
SSST Sets or queries the
sync type. Applies only
to analog outputs.
VRES Sets or queries the
vertical resolution of
the active timing.
Express in number of
lines.
December 1, 2014
Syntax Parameters
HSPG <enable> Where enable is:
HSPG? 0 = disable
1 = enable
< enable >
IMGL <image> Where image is one of the
images listed in Table 7-4
IMGU Not applicable
IMGU?
NBPC <bit_depth> Where bit_depth is one of:
NBPC? 8 – 8 bits per component
10 – 10 bit per component
12 – 12 bits per component
PRAT? Not Applicable
RGBW <pattern> <R> Where pattern is either 4 for
<G> <B> Window pattern or 33 for
raster pattern.
RGBW?
<pattern> <R> <G> Where R G B are the
<B> respective values for the
RGB color components
SCAN <scan> Where scan is:
SCAN? 1 = progressive
2 = interlaced
< scan >
SIRE <range> Where range is a value from
0 to 100.
SSST <sync_type> Where format_type is one of:
SSST? 1 – separate sync
3 – sync on green
VRES <lines> Where lines can be within
the range of:
VRES?
Min = 1 (if scan = 1)
< lines >
Max = VTOT – 1 (if scan = 1)
2)
Command Example
To enable the horizontal sync
pulse:
HSPG 1
ALLU or FMTU
See example below for IMGU
To load and invoke a image
load command:
IMGL SMPTEbar
IMGU
To set the HDMI bit depth to
10:
NBPC 10
ALLU or FMTU
To read the pixel rate of the
outgoing HDMI signal:
PRAT?
+74.2500E+06
To set the Window pattern to
dark brown:
imgl window
imgu
rgbw 4 115 82 68
or
rgbw 4 115 87 74
To set the scan to interlaced:
SCAN 2
ALLU or FMTU
To set the IRE range for any of
the images listed:
SIRE 50
ALLU
To set the analog sync type to
separate sync:
SSST 1
ALLU
To set the horizontal resolution:
VRES 480
ALLU
= 2 (if scan = 2)
= VTOT – 3 (if scan =
