780B Video Generator/Analyzer – User Guide
375
396
397
398
Table 12-3 – Format Range per Interface Map
Interface Number
301 - 309
310 - 331
332 - 336
341 - 398
400 - 499
500 - 599

13.5 Selecting a Test Pattern (Image)

A test pattern (image) can be selected by pressing the PATTERN key followed by the number that represents
the desired pattern. The following is an example of how you would select a test pattern using the Image Map
file shown in Table 12-4 below.
PATTERN
001
ENTER
This will display the SMPTEBar pattern at the current format and on the current interface. Then the "Previous"
and "Next" keys can be pressed to sequence through the pattern list.
Table 12-4 – Example Image Map File
Image Number
001
002
003
004
005
100
101
200
300
301
302
400
December 1, 2014
480i30
720p59
DMT0660
480p60
Interface Name
TV
BNC + S-Video + CVBS (ED/HD)
DVI
HDMI
VGA(HD15) Analog RGB
VGA(HD15) Analog YPbPr
Image Name
SmpteBar
TVBar100
TVBar_75
H_Stair
Pluge
Ramp
SplitGray
LG_V_CBAR
EcoFlower
Halation
Loading
Flat
Page 216
Revision A7
