Quantum Data 780B User Manual page 166

780B Video Generator/Analyzer – User Guide
Note: In the example above the first white space separates the name of the EDID which matches the EDID
file in the 780B for testing and the description that appears on the AutoEDID test screen. The second white
space is part of the description.
2. Transfer this text file to the AutoEDID directory of the 780B. Use the procedures in
Importing EDIDs into the 780B
reference on the AutoEDID directory.
The AutoEDID directory should now include your EDID list file:
The EDID directory would look similar to the following:
December 1, 2014
to transfer the this text file to the 780B. Refer to the figure below for
Page 165
Procedures for
Revision A7
