780B Video Generator/Analyzer – User Guide
4. Power cycle the 780B using the rocker switch on the back panel.
The 780B will appear as a mass storage device on your PC like any other USB drive.
5. If this is the first time you have used the 780B in the Disk mode you will have to reformat the disk. The
system will prompt you through the format process.
6. Transfer your saved Trace text file from the 780B to your PC using standard windows procedures for
transferring files to a USB drive, i.e. dragging and dropping or copying and pasting.
Note: ACA traces are saved in the /Reports/ACA directory.
7. Touch select the Preferences from the 780B top level menu. Refer to the screen below.
8. You can load these trace text files into the Quantum Data ACA available on the Quantum Data website at:
www.quantumdata.com/downloads.
