FIGURE 11-3
11.4

Reading Boot Messages

Use the boot software messages to verify the presence of options in the system.
After POST completes the system self-test, a message similar to the following will
appear on your screen. The message lists hardware detected in the system.
Note – The following screen display is only an example. The actual message
displayed on the screen will vary with the software running on the system.
5-slot Sun Enterprise 3500, Keyboard Present
OpenBoot -.- FCS, --- MB memory installed, Serial #---.
Ethernet address -:-:--:-:--:--, Host ID: ------.
If there is no terminal on this system, you must check the system status by
inspecting LEDs on the front panel (
System Reset Switch on Clock+ Board
).
FIGURE 11-4
Chapter 11
System reset switch
CPU reset switch
Powering Off and On 11-5
