FIGURE 3-2
3. Pull the ends of both extraction levers outward simultaneously to unseat the
board centerplane connector from the centerplane receptacles (
FIGURE 3-3
Caution – If a board is not immediately replaced, a filler panel must be installed in
the board's place to prevent overheating. See Section 3.2 "Filler Panels."
3-6 Sun Enterprise 3500 System Reference Manual • August 2001
Unlocked
Unlocking and Locking Quarter-Turn Access Slots
CPU/Memory+ Board
Locked
Extraction lever
).
FIGURE 3-3
