12.3

Internal Access

The system has a front bezel that must be removed to access the media tray.
12.3.1

Front Bezel

To remove the front bezel:
1. Grasp the front bezel on both sides near the center.
Place your thumbs on top of the front bezel and place your other fingers at the slight
indentations under the front bezel for leverage.
2. Pull the front bezel straight out toward you and set it aside.
Press down on the top of the bezel as you pull it toward you (
FIGURE 12-1
To replace the front bezel, reverse these instructions.
12-2 Sun Enterprise 3500 System Reference Manual • August 2001
Removing the Front Bezel
).
FIGURE 12-1
