8. Hold the card at an angle as depicted in
face plate under the springfingers and against the rear face of the Graphics+ I/O
board front panel.
The I/O connectors of the card should be visible through the opening in the
Graphics+ I/O board front panel once the card is properly positioned.
9. Hold the card by the edges nearest the graphics (UPA) connector and place the
card over the two standoffs.
10. Hold the card by the edges near the connector and firmly but gently press the card
down until the connector is fully seated.
To align the connector and socket, push the card toward the Graphics+ I/O board
front panel.
Caution – Do not rock the card onto the socket; the plastic connector housing may
break.
11. Press each corner of the card to ensure that it rests on the collar of the standoff.
12. Press down on the tip insert of each standoff to lock the card in place.
13. Replace and tighten the front panel screws to secure the card to the Graphics+ I/O
board front panel.
See
FIGURE 4-12
14. Use the procedures in Section 4.6.3 "Installing a Board," to replace the Graphics+
I/O board.
4.6.6 GBICs
Each SBus+ and Graphics+ I/O board has two onboard connectors; each connector
accommodates one GBIC (100 MByte/second Fibre Channel).
4.6.6.1

Removing a GBIC

1. Locate the GBIC to be removed (
on page 4-15
FIGURE 4-17
on page 4-19. Guide the card
FIGURE 4-16
or ).
FIGURE 4-18
Chapter 4 I/O+ Boards and Components 4-21
