Sun Microsystems Enterprise 3500 System Reference Manual page 99

6.3.4 Installing a GBIC
Note – It is not necessary to remove the interface board from the card cage to
remove and replace GBICs. A GBIC may be removed and replaced "live" (without
removing power from the system or board). However, the necessary software
precautions must be taken whenever the I/O path to a particular disk is to be
interrupted; halt all I/O activity to the disk affected by the replacement of a GBIC.
Ensure that the orientation of the alignment groove is correct ( ) and then
FIGURE 6-3
reinsert the GBIC into the proper slot. Reconnect the fiber optic cable as depicted in
(keys on cable matching notches on the GBIC).
FIGURE 6-3
Chapter 6 Interface Board 6-7
