FIGURE 8-6
b. Gently but firmly pull on the handle to slide the drive out of the chassis.
Once the drive is partially removed from the mounting rails, grasp the bottom of
the drive to aid in removal.
4. If the drive is to be replaced, proceed to Section 8.2.3 "Installing a Disk Drive."
8.2.3

Installing a Disk Drive

1. Attach a grounding wrist strap.
Refer to the documentation that came with your antistatic kit.
Caution – You must wear a wrist strap when handling disk drives to prevent
damage to the system components.
8-8 Sun Enterprise 3500 System Reference Manual • August 2001
Retainer
Disk Drive With Retainer Unlatched and Extended
