A P P E N D I X

Functional Description

The 5-slot Enterprise 3500 system is part of the Sun Enterprise server family, which
includes the 16-slot and 8-slot cabinet servers and an 8-slot standalone server.
All systems feature shared-memory multiprocessors and use the same boards,
power/cooling modules (PCMs), and operating software.
This appendix contains the following topics:
Section B.1 "System Overview" on page B-1
Section B.2 "Board Hot-Swapping Procedures" on page B-5
Section B.3 "CPU/Memory+ Board" on page B-5
Section B.4 "I/O+ Boards" on page B-8
Section B.5 "Power Supplies" on page B-12
Section B.6 "Clock+ Board" on page B-15
Section B.7 "Network Interfaces" on page B-16
Section B.8 "Internal Disk Drives" on page B-16
Section B.9 "Media (DVD-ROM/Tape Drive) Tray" on page B-16
Section B.10 "Expansion Cabinets" on page B-16
B.1

System Overview

This section describes the Enterprise 3500 system enclosure (
FIGURE B-2
The front of the cabinet contains the DVD-ROM/tape drives, the key switch, the
internal disk drives, the auxiliary peripheral power supply (PPS1) or thermal
protection module, and the fan tray.
)
and
FIGURE B-1
