D.7

SBus Cards

1. Install double-wide SBus cards only on the SBus+ I/O board in SBus slots 1 and
2. The location of SBus slot 0 prevents its use with double-wide cards.
2. Double-wide SBus cards cannot be used with the Graphics+ I/O board. The
middle card connector does not fit SBus cards.
D.8

CPU Modules

1. Each CPU/Memory+ board has two sets of CPU connectors, marked PROC 0 and
PROC 1.
2. Do not mix CPU speeds.
3. The order in which you fill CPU slots is not critical. However, to optimize heat
dissipation in the system:
TABLE D-1
boards.
TABLE D-1
Slot Number
3
5
7
Fill all PROC 0 locations on all CPU/Memory+ boards before filling any PROC
1 locations. To receive the maximum quantity of diagnostic information, fill
PROC 0 on board 3.
After all PROC 0 locations are filled, you can begin filling the PROC 1
locations, again starting from the lowest slot number to the highest.
shows slot locations for an example of five CPUs on three CPU/Memory+
CPU Placement - Example Only
PROC 0
in
in
in
PROC 1
in
in
—
Appendix D Rules for System Configuration D-5
