Key switch lock
cable assembly
Hook
Key switch
bracket
FIGURE E-10
5. Separate the key switch lock cable from the key switch bracket.
a. Remove the U-shaped key switch keeper by pulling it straight out away from
the key switch lock assembly.
The key switch keeper is located on the inside of the key switch bracket and
secures the cable to the bracket.
b. Remove the key switch lock cable by pulling it through the keyhole
(
FIGURE E-10
Screws
Removing the Key Switch Lock Cable Assembly
).
Appendix E Non-Chassis Field Replaceable Units (FRUs) E-15
