Internal Options

TABLE 1-1
Option Quantity
CPU/Memory+ 5 total per system
boards, SBus+ I/O
boards, Graphics+
I/O boards, PCI+
I/O boards
UltraSPARC II 8 per
modules system
Memory modules 0, 8, or 16 DIMMs per
CPU/Memory+ board
SBus cards 12 per
system
Graphics 4 per
(UPA) cards system
PCI cards Dependent upon card
type, consult your
customer representative
Media tray DVD-ROM drive and
optional tape drive
Interface board 1 per
system
Disk drives 8 internal disk bays
Internal Options for the Enterprise 3500 System
Comments
Each slot can accept four types of boards: CPU/Memory+
board, SBus+ I/O board, Graphics+ I/O board, and PCI+
I/O board. Combinations can vary. Since slot 1 connects to
the onboard SCSI devices, however, this slot should be
reserved for the first I/O+ board. One system board
becomes the system master automatically. Jumper changes
are not needed.
0-2 modules on each CPU/Memory+ board.
DIMM sizes are 8, 32,128, or 256 Mbyte DRAM. Do not mix
sizes within the same bank.
Add 8 DIMMs at a time. Install DIMMs in all bank 0 sockets
first on each CPU/Memory+ board, from the lowest slot to
the highest. Once bank 0 is full, install remaining DIMMs in
bank 1 sockets in the same order.
0-3 cards per SBus+ I/O board, 0-2 cards per Graphics+ I/O
board.
1 card per Graphics+ I/O board.
0-2 cards per PCI+ I/O board.
Media tray takes removable-media drives only.
One DVD-10 is standard equipment per system. One
optional tape drive is supported in the media tray.
4 GBIC slots on the interface board.
Top bank can hold 4 disk drives; bottom bank can hold 4
disk drives. Install disks in bottom bank first, from left to
right, starting with bay 0 (the farthest bay to the left as you
face the front of the system is bay 0. Note: Reserve bay 0 for
boot disk). Also install disks in top bank from left to right.
