7
10
9
FIGURE F-2
Key
Description
7
Auxiliary fan tray
8
PCM
9
Power supply, peripheral/AC input
10
Interface board
11
Clock+ board assembly
12
SBus+ I/O board assembly
13
Graphics+ I/O board assembly
14
CPU/Memory+ board assembly
Rear View
8
11
12
14
13
Part Number
540-2757
300-1260
300-1400
501-4820
501-4946
501-4883
501-4884
501-4882
Appendix F
Illustrated Parts Breakdown
F-5
