Card Cage Slot Information

When installing a board, remember:
Slot numbers
Slot functions
1. See Section D.1 "Card Cage," for an explanation of the missing even-numbered slots.

FIGURE 9-4

For a more complete set of rules for configuring the system, see Appendix D "Rules
for System Configuration."
Board slots are numbered 1, 3, 5, 7, 9
Slot 1 should contain an I/O+ board (connects to media tray).
Aside from the requirement for the I/O+ board, all five card cage
slots are equivalent.
Rear view
7 5 3 1
9

Slot Numbers for the Card Cage

1
, from right to left (
I/O+ board
Board slots (5 total)
Chapter 9 Troubleshooting Overview
.)
FIGURE 9-4
9-7
