G.2.1

Centerplane Connector

Information for the CPU/Memory+ board centerplane and the I/O+ boards
centerplane is the same. See Section G.1.1 "Centerplane Connector" on page G-2.
G.2.2

SBus Connectors

Two I/O+ boards have SBus connectors:
The SBus+ I/O board has three SBus connectors, SBus 0, 1, and 2 (
The Graphics+ I/O board has two SBus connectors, SBus 0 and 2 (
SBus 0
FIGURE G-7
G-6 Sun Enterprise 3500 System Reference Manual • August 2001
SBus 2
SBus 1
SBus I/O+ Board SBus Connectors
).
FIGURE G-7
).
FIGURE G-8
