Unlocking and Locking Quarter-Turn Access Slots
FIGURE 4-6
4. Pull the ends of both extraction levers outward simultaneously to unseat the
board centerplane connector from the centerplane receptacles (
Extraction Lever in Extract Position
FIGURE 4-7
Caution – If a board is not immediately replaced, a filler panel must be installed in
the board's place to prevent overheating. See Section 4.2 "Filler Panels."
Unlocked
Extraction lever
Chapter 4
Locked
FIGURE 4-7
I/O+ Boards and Components
).
