2. Remove the GBIC from the I/O+ board by compressing the locking tabs located
on either side of the card and pulling straight out from the opening in the I/O+
board panel (
FIGURE 4-19
4.6.6.2

Installing a GBIC

1. Locate the GBIC slot for installation (
2. Ensure correct orientation for insertion.
The alignment slots are on the bottom of the GBIC (
3. Insert the GBIC into the I/O+ board panel slot and then push in to firmly seat the
card.
An audible click indicates the GBIC is properly seated to the onboard connector.
).
FIGURE 4-19
Removing or Installing a GBIC
Alignment slot
or
FIGURE 4-17 FIGURE 4-18
FIGURE 4-19
