7. Place the card in an antistatic bag.
8. If the graphics (UPA) card is not immediately replaced, install a filler panel (part
number 340-2305) on the Graphics+ I/O board front panel opening.
To secure the filler panel, use the screws that were removed in Step 3.
Caution – Be sure to install the filler panel right-side up. Installing it upside down
creates a gap at the top edge of the card slot opening that can impair system cooling
and FCC regulatory compliance.
9. Use the procedures in Section 4.6.3 "Installing a Board," to replace the Graphics+
I/O board.
4.6.5.2 Installing a Graphics (UPA) Card
1. Use the procedures described in Section 4.6.2 "Removing a Board," to remove the
applicable Graphics+ I/O board.
2. Attach a wrist strap and take the graphics (UPA) card out of the protective
packaging and place the card on an antistatic mat.
Inspect the pins in the connector to make sure they are not bent.
3. Remove the adapter bracket from the rear panel of the card.
See
FIGURE 4-13
card rear panel (the adapter bracket and the screws are not needed for this
installation).
4. Remove the black plastic card retainer shipped with the card.
See
FIGURE 4-14
the card (the retainer is not needed for this installation).
5. Locate the graphics (UPA) connector for the card.
See
FIGURE 4-15
6. If a filler panel covers the Graphics+ I/O board front panel slot for the graphics
(UPA) card, remove the two screws and detach the filler panel.
Retain the screws to attach the graphics (UPA) card to the front panel, unless the
card has a wide connector, or set of connectors.
7. Unlock the tip inserts for the two standoffs for the graphics (UPA) connector slot.
See
FIGURE 4-11
4-20 Sun Enterprise 3500 System Reference Manual • August 2001
on page 4-16. Remove the two screws securing the adapter to the
on page 4-17. Spread the ends of the retainer apart to remove it from
on page 4-18.
on page 4-14.
