7. Use the extraction levers to seat the power supply.
Simultaneously swing both levers inward to the locked position. Do not press on the
front panel of the power supply to seat it—doing so will damage the connector pins.
8. Lock the power supply to the system chassis by tightening the captive screws.
9. Check to be sure the green LED on the power supply is lit.
If the green LED is not lit, the power supply may not be seated properly. Check to
see if it is seated properly by repeating Step 5 to Step 9. If the green LED is still not
lit, see Chapter 10 "Flow Diagrams for Troubleshooting," for more information.
If the green LED is lit, you see a message similar to the following example on your
system console:
NOTICE: Peripheral Power Supply 1 Installed
NOTICE: Peripheral Power Supply 1 OK
