FIGURE 4-21
5. Once the card is free of the PCI bus connector and the metal catch mechanism,
remove the card from the I/O board (
4.6.7.2 Replacing or Installing a PCI Card
1. Ensure that the voltage type of the PCI card you are replacing or installing
matches the voltage type of the riser card, either 5.0V or 3.3V (66 MHz-capable).
2. Verify that the JTAG test jumper is removed/disabled (
Note – PCI+ I/O boards purchased from Sun Microsystems are shipped with the
JTAG test jumper disabled or removed on both of the 5.0V riser cards installed on
the board.
4-26 Sun Enterprise 3500 System Reference Manual • August 2001
PCI Card Removal
Catch mechanism
).
FIGURE 4-21
FIGURE 4-22
).
