CDM-710 Broadcast Satellite Modem
Front Panel Operation

INFO: Rx

RX: 0140.0000 17.379483
DVBS2 QP 1/2 LF
The info items are as follows:
0140.0000
17.279483
DVBS2
QP
8P
16Q
16A
32A
1/2
LF

INFO: INTFCx

Intfc1: ASI DISABLED
188 J4 Wide
ASI Only:
ASI
Enabled
188
J4
Wide
Tx Frequency in MHz
Data rate in Mbps
Transmission mode:
DVBS2
DVB-S
DSNG
Modulation:
QP = QPSK
8P = 8-PSK
16Q = 16-QAM
16A = 16-APSK
32A = 32-APSK
Code Rate
FECFrame Type
SF = Short Frame
LF = Long Frame
Interface Type
ASI = Asynchronous Serial Interface per DVB
GBEI = Gigabit Ethernet
Enable / Disable status
Transport Stream Frame Type
188 = 188 byte frame ; 204 = 204 byte frame
Tx Data Input Connector on Data Interface
J4 or J5
Bandwidth Selection ASI (Tx Data)
Wide or Narrow
5–52
