CDM-710 Broadcast Satellite Modem
Front Panel Operation

Config: Remote Control: Ethernet: Gateway

Gateway
If is selected:
Ethernet IP Gateway:
063.168.001.127
Use the  arrow keys to edit the Gateway address and press

Config: Remote Control: Ethernet: Address

Address
If is selected:
Ether IP Address/Range:
192.168.001.001/24
Use the  arrow keys to edit the IP Address/Range address and press
the value. The range is adjustable from 08 to 30.

Config: Remote Control: Ethernet: MAC

MAC
If is selected:
M&C Port MAC Address:
00-06-B0-00-56-33
This is a status only message.
Note: The preceding address is representative of a typical MAC address.

Config: Remote Control: Ethernet: SNMP

SNMP
If is selected:
SNMP:
Community Traps
This is a status only message. Sub menus enable setting of the destination IP address
for SNMP traps.
( E )
()
(LRE)
5–9
Revision 9
MN/CDM710.IOM
ENTER to accept the value.
ENTER to accept
