CDM-710 Satellite Modulator
Remote Control
Command
Parameter (Instruction for Command
Type Code and
Qualifier)
Equipment ID N/A 23 bytes
Arguments
Description of Arguments
or Response
to Query
Unit returns equipment identification and configuration,
where:
aaa = defines the modulator model number (710)
b = Modulator configuration:
0=None, 1=70/140 Mhz, 2=L-Band
c = Tx Symbol Rate S/W option: 0 = 15.0 Msps,
1 = 22.5 Msps, 2 = 30.0 Msps,
3 = 37.5 Msps (S1 and DSNG only),
4 = 45.0 Msps (S1 and DSNG only)
d = S/W option Tx 8PSK: 0=Not installed, 1=Installed
e = S/W option Tx 16-QAM: 0=Not installed, 1=Installed
f = S/W option Tx 16APSK: 0=Not installed, 1=Installed
g = S/W option Tx 32APSK: 0=Not installed, 1=Installed
h = S/W option Tx DVB-S1: 0=Not installed, 1=Installed
i = S/W option Tx DVB-DSNG: 0=Not installed, 1=Installed
j = S/W option Tx DVB-S2: 0=Not installed, 1=Installed
k = Demodulator configuration:
0=None, 1=70/140 Mhz, 2=L-Band
l = Rx Symbol Rate S/W option: 0=15.0 Msps,
1 = 22.5 Msps, 2 = 30.0 Msps,
3 = 37.5 Msps (S1 & DSNG only),
4 = 45.0 Msps (S1 & DSNG only)
m = S/W option Rx 8PSK: 0=Not installed, 1=Installed
n = S/W option Rx 16-QAM: 0=Not installed, 1=Installed
o = S/W option Rx 16APSK: 0=Not installed, 1=Installed
p = S/W option Rx 32APSK: 0=Not installed, 1=Installed
q = S/W option Rx DVB-S1: 0=Not installed, 1=Installed
r = S/W option Rx DVB-DSNG:0=Not installed, 1=Installed
s = S/W option Rx DVB-S2: 0=Not installed, 1=Installed
t = Interface slot #1: 0 = None, 1 = ASI, 2 = Gigabit Ethernet
Interface, 3 = HSSI
u = Interface slot #2: 0 = None, 1 = ASI, 2 = Gigabit Ethernet
Interface, 3 = HSSI
Response
to
Command
EID=
EID?
EID*
EID#
A–65
Revision 9
MN/CDM710.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
EID? EID=
aaabcdefghijklmnopqrstu
