Comtech EF Data CDM-710 Installation And Operation Manual page 223

CDM-710 Satellite Modulator
Remote Control
Command
Parameter (Instruction for Command
Type Code and
Qualifier)
Rx Eb/No N/A 4 bytes
Rx Es/No N/A 4 bytes
Rx PER N/A 7 bytes
Rx BER N/A 7 bytes
Arguments
Description of Arguments
or Response
to Query
Query only.
Unit returns the value of Eb/No (when in DVB-S or DVB-DSNG
mode), between 0 and 16 dB, resolution 0.1 dB.
Returns 99.9 if demod is unlocked.
Example EBN=12.3 (which is Eb/No = 12.3 dB)
For values greater than 16.0 dB, the reply will be: EBN=+016
Query only.
Unit returns the value of EsNo (when in DVB-S2 mode),
between 0 and 16 dB, resolution 0.1 dB.
Returns 99.9 if demod is unlocked.
Example ESN=12.3 (which is Es/No = 12.3 dB)
For values greater than 22.0 dB, the reply will be: ESN=+022
Query only.
Units returns the value of the estimated PER in the form ab x 10
. First three bytes are the value. Last two bytes are the exponent.
Returns 0.0E+00 if the demodulator is unlocked.
Example: PER=4.8E-03 (which is PER = 4.8 x 10
Query only.
Units returns the value of the estimated BER in the form ab x 10
First three bytes are the value. Last two bytes are the exponent.
Returns 0.0E+00 if the demodulator is unlocked.
Example: BER=4.8E-03 (which is BER = 4.8 x 10
Response
to
Command
N/A
N/A
N/A
-c
-3
)
N/A
-c
.
-3
)
A–62
Revision 9
MN/CDM710.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
EBN? EBN=xxxx
ESN? ESN=xxxx
PER? PER=a.bEscc
BER? BER=a.bEscc
