CDM-710 Broadcast Satellite Modem
Summary of Specifications
Description
1:1 Redundancy
Fault
Configuration
External Tx Carrier Off
Agency Approval
8.2

Environmental and Physical

Description
Temperature:
Operating
Storage
Humidity:
Operating
Storage
Power Supply Input
Power Supply Input
Fuse
Power Consumption
AC Power Cord Retainer
Modular design
Dimensional Envelope, 1RU
Weight
Keypad and Display
Built in controller for operation with optional CRS-170A for L-Band and CRS-180 for
70/140 MHz
Form C, see connector pinout information and notes
Non-volatile for 1-year minimum and returns upon power up.
TTL low signal – path bypasses microprocessor (Alarm Conn)
Safety, conducted and radiated emissions and Immunity sufficient for CE certification
0 to 50ºC (32 to 122ºF)
-20 to 70ºC (-4 to 158ºF)
95% maximum, non-condensing
99% maximum, non-condensing
100-240AC 50/60Hz, auto-ranging
-48VDC
AC, T2.00A, 5x20 mm.250VAC time lag
DC, T6.25A, 6.3x32mm.(3AG), 250VAC time lag
< 75 W, 55W typical
Standard
Simplex or Duplex
1.72H x 19.00W x 18.65D inches
(4.37H x 48.26W x 47.37D cm)
15lbs (6.8 kg)
2 lines x 24-character display with up, down, left, right, Clear, and Enter keys.
8–2
Requirements
Requirements
