CDM-710 Satellite Modulator
Remote Control
Command
Parameter (Instruction for Command
Type Code and
Qualifier)
Real-time TIM= 6 bytes
Clock Time
Temperature N/A 3 bytes
Unit Test Mode TST= 1 byte
Test Pattern TPT= 1 byte
Arguments
Description of Arguments
or Response
to Query
A time in the form hhmmss, indicating the time from midnight,
where:
hh = hours (00 to 23)
mm = minutes (00 to 59)
ss = seconds (00 to 59)
Example: TIM=231259 (23 hours:12 minutes:59 seconds)
Unit returns the value of the internal temperature, in the form of
sxxx (degrees C). Where s is the sign and and xxx is the number
of degrees.
Example: TMP=+026
Test Mode, where:
0=Normal Mode (no test)
1=IF Loop
2=I/O Loop
3=RF Loop
4=Tx CW
5=Tx Alternating 1,0 Pattern
Example: TST=4 (Tx CW)
Set Test Pattern , where:
0=Off
1=2047
2=2^23-1
Example: TPT=1 (2047)
Response
to
Command
TIM=
TIM?
TIM*
TIM#
N/A
TST=
TST?
TST*
TST#
TPT=
TPT?
TPT*
TPT#
A–75
Revision 9
MN/CDM710.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
TIM? TIM=hhmmss
TMP? TMP=sxxx
TST? TST=x
TPT? TPT=x
