CDM-710 Satellite Modulator
Remote Control
Command
Parameter (Instruction for Command
Type Code and
Qualifier)
Local/Remote LRS= 1 byte
Status
Unit MAC N/A 12 bytes
Address
Unit Alarm MSK= 2 bytes
Mask
Number of N/A 3 bytes
Unread stored
Events
Soft Reboot RBT= 1 byte
Enable ESW= 1 byte, value
Redundancy of 0 or 1
Switch Mode
Arguments
Description of Arguments
or Response
to Query
Local/Remote status, where:
0=Local
1=Serial
2=Reserved
3=Ethernet
Example: LRS=1 (which is remote Serial)
MAC address of the unit, reported in hexadecimal.
Example: MAC=0006B000D2A7 (The MAC address of the unit
is 00:06:B0:00:D2:A7 )
Alarm mask conditions, in form ab, where:
a=Tx AIS (0 = Alarm, 1 =Fault, 2 = Masked)
b=Spare
Example: MSK = 00
Unit returns the Number of stored Events, which remain Unread,
in the form xxx.
Note: This means unread over the remote control.
Example: NUE=126
Soft Reboot.
1= Reboot System
Set redundancy mode, where :
0 = Disable
1 = Enable
Example: ESW=1 (Enable redundancy mode)
Response
to
Command
LRS=
LRS?
LRS*
LRS#
MAC=
MAC?
MAC*
MAC#
MSK=
MSK?
MSK*
MSK#
N/A
RBT=
RBT?
RBT*
RBT#
ESW=
ESW?
ESW*
ESW#
A–44
Revision 9
MN/CDM710.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
LRS? LRS=x
MAC? MAC=AABBCCDDEEF
F
MSK? MSK=ab
NUE? NUE=xxx
N/A RBT=x
ESW? ESW=x
