CDM-710 Satellite Modulator
Remote Control
Command
Parameter (Instruction for Command
Type Code and
Qualifier)
Gigabit Source

GSI=

17 bytes
IP Address
Gigabit Primary

GSP=

2 bytes
Stream
Gigabit Stream

GSM=

2 bytes
Mode
Gigabit Stream

GTO=

3 bytes
Timeout
Gigabit Stream

GTM=

2 bytes
Timeout Mode
Arguments
Description of Arguments
or Response
to Query
Gigabit Source IP Address
s=Slot (1, 2)
m=Multicast Stream (1, 2)
i=IP Address
Gigabit Primary Stream
s=Slot (1, 2)
m=Multicast Stream (1, 2)
Gigabit Stream Mode
s=Slot (1, 2)
m=Mode
1=Single Stream
2=Dual Stream (Redundancy Mode)
Gigabit Stream Timeout (Only used when in Dual Stream Mode).
s=Slot (1, 2)
t=Timeout in 100 mS intervals (0 – 10)
Gigabit Stream Timeout Mode (Only used when in Dual Stream
Mode)
s=Slot (1, 2)
m=Mode
0 = Non-revertive
1 = Revertive
***When in redundancy mode (GSM = 1 ), this parameter
controls whether the Gigabit Interface switches back and forth
between the two input streams for a valid MPEG stream.
Revertive means the interface will switch back and forth between
the two streams. Non-revertive is a latching scheme where the
interface will only switch to the secondary stream.
Response
to
Command
GSI =
GSI #
GSI?
GSI *
GSP=
GSP#
GSP?
GSP*
GSM=
GSM#
GSM?
GSM*
GTO=
GTO#
GTO?
GTO*
GTM=
GTM#
GTM?
GTM*
A–70
Revision 9
MN/CDM710.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
GSI?sm GSI=smiii.iii.iii.iii
GSP?s GSP=sm
GSM?s GSM=sm
GTO?s GTO=stt
GTM?s GTM=sm
