CDM-710 Broadcast Satellite Modem
Installation

2.2.1 Optional Rear-Mounting Support Brackets

Install optional rear-mounting support brackets using mounting kit KT/6228-2:
Quantity
The tools required for this installation are a medium Phillips screwdriver and a 5/32-inch
SAE Allen Wrench. The kit is installed as illustrated in Figure 2-1 and per the following
procedure:
Step Procedure
Secure the #10 shoulder screws to the unit chassis through the rear right and left side
1 mounting slots, using the #10 flat washers, #10 split washers, and #10 hex nuts as
shown.
Install the rear support brackets onto the equipment rack threaded rear mounting
2
rails, using the #10 rack bracket bolts.
Mount the unit into the equipment rack, ensuring that the shoulders of the #10
3
shoulder screws properly engage into the rear support bracket slots.
Part Number
2 HW/10-32SHLDR
4 HW/10-32FLT
2 HW/10-32SPLIT
2 HW/10-32HEXNUT
2 FP/6138-1
4 HW/10-32x1/2RK
Screw, #10 Shoulder
Washer, #10 Flat
Washer, #10 Split
Nut, #10 Hex
Bracket, Rear Support
Bolt, #10 Rack Bracket
2–2
Revision 9
MN/CDM710.IOM
Description
