CDM-710 Satellite Modulator
Remote Control
Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
Description of Arguments
to Query
b = Tx Traffic Status:
0=No faults
1= +1.5V Power Supply Unit (Modulator Card)
2= FPGA Failed to Load (Modulator Card)
3= Symbol Rate PLL Clock
4= Tx Synthesizer Unlocked
5= Tx Digital Clock Manager Unlocked
6= I & Q Baseband Channels are Inactive
7= FPGA Temperature (Modulator Card)
8= Nyquist Filter Clipping
9= ASI Port Transmit FIFO Empty (Interface 1)
A= ASI Port Transmit FIFO Empty (Interface 2)
B= ASI Port Transmit FIFO Full (Interface 1)
C= ASI Port Transmit FIFO Full (Interface 2)
D= ASI Port Transmit Data Loss (Interface 1)
E= ASI Port Transmit Data Loss (Interface 2)
F= ASI Frame Not Synchronized (Interface 1)
G= ASI Frame Not Synchronized (Interface 2)
H= HSSI TX Clock Failure (Interface 1)
I= HSSI TX Clock Failure (Interface 2)
J= GBEI Card Datarate > 200 PPM
K= GBEI Card Datarate < 200 PPM
L= GBEI No PHY Link
M= Encoder FIFO Empty
N= Encoder FIFO Full
O= ASI Tx Input Datarate Offset > +110PPM (Interface 1)
P= ASI Tx Input Datarate Offset > +110PPM (Interface 2)
Q= ASI Tx Input Datarate Offset < -110PPM (Interface 1)
R= ASI Tx Input Datarate Offset < -110PPM (Interface 2)
S= SERDES Parity Errors
Response
to
Command
A–67
Revision 9
MN/CDM710.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
