CDM-710 Satellite Modulator
Remote Control
Command
Parameter (Instruction for Command
Type Code and
Qualifier)
Rx Clock RCI= 2 bytes
Invert
Rx Clock RCK= 2 bytes
Source
Enable/Disable AEQ= 1 byte
Adaptive
Equalizer
Eb/No Alarm

EBA=

4 bytes
Point
Arguments
Description of Arguments
or Response
to Query
Command or Query. Invert Receive Clock, where:
s=Defines which interface slot ( 1 or 2 )
x=Invert Receive Clock, where:
0=Normal
1=Inverted
(Note: Command valid Only with HSSI)
Example: RCI = 11 (selects Inverted RX Clock, Slot 1)
Command or Query. Rx Clock Source (For Data Rate
Accuracy), where:
s=Defines which interface slot ( 1 or 2 )
x=Rx Clock Source, where:
0=Rx Satellite
1=Tx-Terrestrial
2=External Reference Clock
3=Internal (HSSI Only)
Example: RCK=11 (selects Tx-Terrestrial)
Adaptive Equalizer status, where:
0=Disable
1=Enable
Example: AEQ=1 (which is Enable)
Command or Query.
Eb/No alarm point in dB, with a range between 0.1 and 16 dB.
Resolution=0.1 dB
Example: EBA=12.3
Response
to
Command
RCI =
RCI?
RCI *
RCI #
RCK=
RCK?
RCK*
RCK#
AEQ=
AEQ?
AEQ*
AEQ#
EBA=
EBA?
EBA*
EBA#
A–32
Revision 9
MN/CDM710.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
RCI?s RCI =sx
(see description of
arguments)
RCK?s RCK=sx
(see description of
arguments)
AEQ? AEQ=x
EBA? EBA=xx.x
(see description of
arguments)
