CDM-710 Broadcast Satellite Modem
Front Panel Operation
Group
If is selected:
Intfc2 Egress Multicast:
239.010.010.010
Enter the valid destination IP multicast group address for egress IP packets.
Src Port
If
Intfc2 Egress Src Port:
01024
Enter a valid UDP source port address for your network.
Dest Port
If
Intfc2 Egress Dest Port:
01024
Enter a valid UDP destination port address for the egress packet stream. Media packets will be
addressed to this UDP port; FEC packets (if FEC generation is enabled) will be addressed to
(UDP destination port +2).

Config: Intfc1: Man

Man
If (Management) is selected:
Intfc2 Management IP
192.168.001.008/24
Enter management IP address/subnet mask for Gigabit Ethernet Interface management channel.

Config: Intfc1: Stats

Stats
If is selected:
Intfc1 Statistics
View Clear
View
If is selected:
FPGA Packets Dropped
00000000000000000000
Note: The following statistics may be viewed:

is selected:

is selected:

()
5–31
Revision 9
MN/CDM710.IOM
