CDM-710 Broadcast Satellite Modem
Front Panel Operation
5.3.1.10
Tx
If is selected:
Tx Alarm Mask: None
Currently, masking of Tx Alarms (associated with the modulator) is not allowed.

Config: Alarm: Intfc2

Note: This message is only valid for the ASI Interface.
If Intfc2 is selected:
Intfc1 Alarms: TxClk
Intfc1 Alarms: TxClk
The
clock is lost on the incoming data. This often occurs when the data cable is disconnected. Press
Enter for the menu to choose the fault action.

5.3.2 Monitor

Monitor: Alarms
Event-Log
Alarms are reported under three main categories.



See table 5.5, Summary of Alarms Reported for Tx and Unit Categories, for additional
information regarding alarms.

Monitor: Alarms: Live Alarms: Transmit

TX Traffic:
PHY Not Connected
This will only report if there are modulator errors, otherwise it will report "No Errors." The alarm
above usually indicates the data cable is disconnected from the modem.

Alarm: Tx

( E)
menu allows the user to designate the action when the Tx
Rx_Stats
Tx path alarms are displayed under the Tx Category
Rx path alarms are displayed under the Rx Category
Alarms common to the unit are available under the Unit selection
GBEI Card
(E)
5–42
Revision 9
MN/CDM710.IOM
