CDM-710 Satellite Modulator
Remote Control
Command
Parameter (Instruction for Command
Type Code and
Qualifier)
Gigabit Egress GEF= 2 bytes
FEC Enable
Gigabit Egress GEG= 16 bytes
Multicast
Group Address
Gigabit Egress GEP= 11 bytes
Port Numbers
Gigabit Egress GFM= 5 bytes
FEC Matrix
Initialize

IEP=

None
Events Pointer
Boot Image

IMG=

1 byte
Arguments
Description of Arguments
or Response
to Query
Gigabit Egress FEC Enable/Disable.
s=Slot (1, 2)
n=Enable / Disable, where
0 = Disabled
1 = Enabled
Gigabit Egress Multicast Group Address. The multicast stream
egressing from the gigabit interface will have this ip address as
the source IP address.
s=Slot (1, 2)
iii.iii.iii.iii=IP Address
Gigabit Egress Port Numbers
s=Slot (1, 2)
nnnnn = Source Port Number (0 – 65535)
ppppp = Destination Port Number (0 – 65535)
Gigabit Egress FEC Matrix.
s=Slot (1, 2)
ll = Length, two digit number (leading zero) between 1 and 20.
dd = Depth, two digit number (leading zero) between 4 and 20.
**( Length x Depth, must be less than or equal to 100 )
Resets internal pointer to allow RNE? queries to start at the
beginning of the stored events log.
Boot image selection, where n is the image number:
1=Image #1
2=Image #2
Example: IMG=1 (Selects Image #1 for booting.)
Response
to
Command
GEF=
GEF#
GEF?
GEF*
GEG=
GEG#
GEG?
GEG*
GEP=
GEP#
GEP?
GEP*
GFM=
GFM #
GFM?
GFM*
IEP=
IEP#
IMG=
IMG?
IMG*
IMG#
A–71
Revision 9
MN/CDM710.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
GEF?s GEF=sn
GEG?s GEG=siii.iii.iii.iii
GEP?s GEP=snnnnnppppp
GFM?s GFM=slldd
N/A N/A
IMG? IMG=n
