CDM-710 Broadcast Satellite Modem
Preface
IMPORTANT

Recommended Standard Designations

Recommended Standard (RS) Designations have been superseded by the new designation of the
Electronic Industries Association (EIA). References to the old designations are shown only when
depicting actual text displayed on the screen of the unit (RS-232, RS-485, etc.). All other
references in the manual will be shown with the EIA designations.

Electrical Safety

The CDM-710 Broadcast Satellite Modem has been shown to comply with the following safety
standard:
EN 60950: Safety of Information Technology Equipment, including electrical
business machines
The equipment is rated for operation over the range 100 to 240 VAC. It has a maximum power
consumption of 60 watts, and draws a maximum of 600 mA.
The user should observe the following instructions:
IMPORTANT

Fuses

The CDM-710 is fitted with two fuses - one each for line and neutral connections. These are
contained within the body of the IEC power inlet connector, behind a small plastic flap.
For 115 and 230 volt AC operation, use T2.00A, 20mm fuses.
For 48 VDC operation, use T6.25A, 6.3x32mm fuses.
FOR CONTINUED OPERATOR SAFETY, ALWAYS REPLACE THE FUSES WITH
THE CORRECT TYPE AND RATING.
CAUTION
Indicates information critical for proper equipment function.
xiii
Revision 9
MN/CDM710.IOM
