CDM-710 Satellite Modulator
Remote Control
Priority System = RMM (Highest priority), RMD, RCR, and RSR (Lowest Priority). Any change to a higher priority parameter can override any
of the parameters of lower priority.
Command
Parameter (Instruction for Command
Type Code and
Qualifier)
Rx Mode RMM= 1 byte
Rx Modulation RMD= 1 byte
Type
Arguments
Description of Arguments
or Response
to Query
Rx Mode, where:
0=DVB-S
1=DVB-S2
2=DVB-DSNG
Example: RMM=0 (which is DVB-S mode)
*NOTE: Please refer to Ch.8 for available code rates, modulation
types, and symbol rates for each mode.
Rx Modulation type, where:
0=QPSK
1=8PSK
2=16QAM
3=16APSK
4=32APSK
Example: RMD=1 (which is 8PSK)
*NOTE: Please refer to Ch.8 for available modulation types for
each mode.
Response
to
Command
RMM=
RMM?
RMM*
RMM#
RMD=
RMD?
RMD*
RMD#
A–55
Revision 9
MN/CDM710.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
RMM? RMM=x
RMD? RMD=x
