CDM-710 Satellite Modulator
Remote Control
Command
Parameter (Instruction for Command
Type Code and
Qualifier)
External ERF= 1 byte
Reference
Frequency
Faults and N/A 4 bytes
Status
Arguments
Description of Arguments
or Response
to Query
External Reference Frequency, where:
0=Internal
1=External 1 MHz
2=External 2 MHz
3=External 5 MHz
4=External 10 MHz
5=External 20 MHz
Example: ERF=0 (External reference not used - uses internal)
Unit returns the current fault and status codes for the Unit
(hardware), Tx Traffic and Rx Traffic, in the form abcd, where:
a = Unit Faults:
0=No faults
1=Framer FPGA Load
2=Power supply fault, +1.5 Volts, Framer Card
3=Power supply fault, +1.5 Volts, Interface #1
4=Power supply fault, +1.5 Volts, Interface #2
5=Power supply fault, +3.3 Volts, Framer Card
6=Power supply fault, +5.0 Volts, Framer Card
7=Power supply fault, +12.0 Volts, Framer Card
8=Power supply fault, -12.0 Volts, Framer Card
9=Power supply fauilt, +18.0 Volts, Framer Card
A=FLASH Checksum
B=FEC1 Load
C=FEC2 Load
D=Interface #1 Load
E=Interface #2 Load
F=192 MHz PLL
G=External Reference
H=Framer Card Temperature
I=Modem Temperature
J=Cooling Fans
K=Interface #1 Removed
L=Interface #2 Removed
Response
to
Command
ERF=
ERF?
ERF*
ERF#
N/A
A–19
Revision 9
MN/CDM710.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
ERF? ERF=x
FLT? FLT=abcd
d=Change in fault status
since last poll.
Note: Each section has
faults listed in order of
priority. For each
section, only the highest
priority fault is returned.
There maybe multiple
faults for each section,
but only the highest fault
is returned.
